CABINET CONSTRUCTION:
-
.040 copper aluminum exterior.
-
White, vinyl coated aluminum interior top cabinet liner with 300 series stainless steel floor. Construction of liner in accordance with NSF standards.
-
Cabinet mounted on a welded, galvanized frame rail, painted for additional corrosion protection.
-
Safety shielded fluorescent interior lighting.
DOORS:
-
Triple pane thermal insulated glass. Doors extend full width of cabinet shell. Door gaskets of one piece construction.
-
Adjustable, self closing, torsion type closure system. The face of each door fitted with a 12" long handle.
INSULATION:
-
Entire cabinet structure insulated, using foamed-in-place CFC free polyurethane foam.
SHELVING:
-
6 removable 19 5/8” glass shelves. Bottom mirrored shelf for reflective display. Shelves capable of supporting up to 30 lbs.
-
Shelves slowly revolve.
REFRIGERATION SYSTEM:
-
Refrigeration system factory balanced using CFC free 134A refrigerant.
-
Bottom mounted condensing unit - easy access for maintenance.
-
Factory pre-engineered capillary tube system with oversized condenser and evaporator to reduce product pull down time and to consistently maintain 33°F to 38°F interior cabinet temperature. (non-adjustable capillary tube system superior to problematic expansion valve)
-
Evaporator - epoxy coated at the time of manufacture to eliminate the potential of corrosion.
ELECTRICAL CHARACTERISTICS:
-
Unit completely pre-wired at factory, and ready for final connection to a 115/60/1 phase - 15 amp dedicated outlet. A cord and plug set to be included.
-
A sole use circuit is required.
