CONSTRUCTION
* Welded tank with an extra smooth peened finish ensures easy cleaning.
* Long lasting, high temperature alloy stainless steel heat baffles are mounted in the heat exchanger tubes to provide maximum heating and combustion.
* Standing pilot light design provides a ready flame when heat is required.
* Stainless steel front, door, sides and splash back.
CONTROLS
* Solstice burner/baffle design.
-Increases cooking production
-Lowers flue temperature
-Improves working environment
-Generates more production per BTU
* Thermostat maintains selected temperature automatically between 200°F (93°C) and 400°F (190°C).
* Integrated gas control valve acts as a manual and pilot valve, automatic pilot valve, gas filter, pressure regulator, and automatic main valve.
* Gas control valve prevents gas flow to the main burner until pilot is established and shuts off all gas flow automatically if the pilot flame goes out.
* Temperature limit switch safely shuts off all gas flow if the fryer temperature exceeds the upper limit.
| Dimensions and Weight | |
|---|---|
| Gas Inlet Size | 3/4" |
| Exterior Width | 15-5/8" |
| Exterior Depth | 32" |
| Exterior Height | 46-5/16" |
| Capacity | 35 lb. |
| Fry Pot Depth | 14-1/2" |
| Fry Pot Height | 4" |
| Fry Pot Width | 14" |
| Features | |
| Total BTU/HR | 70,000 |
| Burner Style | Tube |
| Cabinet Type | Stainless Steel |
| No. of Fry Baskets | 2 |
| No. of Fry Pots | 1 |
| Split Pot | No |
| Temperature Range | 200 - 400° F |
| Electrical | |
| Power Type | Natural Gas |
| Certificate Label | |
| Energy Star Qualified | Yes |
| NSF Listed | Yes |
